Single Deflection Grille & Register

Single deflection grilles and registers use a single-layer adjustable blade system for supply or return air with the same high-quality extruded aluminium construction as the double deflection family. Blades mounted at 40-degree angles to PVC bushes allow rattle-free movement of air; frames punched rigidly with corners, standard flange width 30 mm. Blades available in horizontal or vertical orientation; a register incorporates an integral damper for air volume control; suitable for heating, cooling and ventilation. Supply model range AR-SG-H / AR-SG-V, registers AR-SGR-H / AR-SGR-V; grilles and registers handle a wide range of airflows at high temperature differentials. Finishes RAL 9010 / 9016 (white tones) with custom colours on request; concealed fixing via spring-clip or face screw fixing. Standards & Certifications: ASHRAE, SMACNA Typical Applications: side-wall supply and return, ceiling and wall registers, residential and commercial ventilation, cooling and heating zones Key Differentiators: single-layer adjustable blades; horizontal or vertical blade orientation; 40-degree rattle-free blade mounting; integral damper register option; RAL 9010/9016 finishes
